FRONT - SRT8

NOTE: Brake pads need to have the shims and cooper paste applied. Paste is applied between the shim and the backing plate of the pads, and along the edges of the pads.

(Refer to 22 - TIRES/WHEELS - INSTALLATION)
(Refer to 5 - BRAKES/HYDRAULIC/MECHANICAL/FLUID - STANDARD PROCEDURE)
NOTE: When NEW brake pads are installed, they must be burnished (seated) to the rotor. This must be done to ensure the proper performance of the replacement brake pads.
(Refer to 5 - BRAKES/HYDRAULIC/MECHANICAL/BRAKE PADS/SHOES - STANDARD PROCEDURE)
